General Incubator, Programmable

Heated Incubator
10-Step Programmable
Temperature Range ambient +5 °C to +70 °C
Chamber Volume:
- - 50 liters (JSGI-050T)
  - 100 liters (JSGI-100T)
  - 150 liters (JSGI-100T)
  - 250 liters (JSGI-100T)

Specifications

Heating System	Forced Air Convection
Temp. Range	ambient+5 ^oC ~ 70 ^oC
Accuracy	± 0.2 ^oC at 37.0 ^oC (JSGI-050T)
Uniformity	± 0.5 ^oC at 37.0 ^oC (JSGI-050T)
Controller	JIC-CON 5th Generation Programmable Temperature Controller
Program	1 Pattern, 10 Steps, 1 ~ 999 (or unlimited) times repreat
	3-Zone Temperature Control Algorithm
	3-Point Temperature Calibration
	1-Point Temperature Offset Calibration
Sensor	Class A Pt-100 Ω Sensor
Safety	Over-Temperature Cut-Off
	Over Current Cut-Off
Material	Body – Epoxy Powder Coated Steel
	Chamber – Stainless Steel 304
	Inner Door – 5 mm thick Tempered Safety Glass
	including PVC coated wire shelf
	optional perforated stainless steel shelf
Electrical Data	220±10% VAC 50/60Hz 1-Phase
Plug config.	CEE 7/7 Schuko or BS 1363

One pattern 10 steps program – User can compose 10 steps of varying temperature program and can save it in a memory. Composed program can be repeated 1 ~ 999 times or unlimited number of time.
3 group zone PID algorithm – Complete temperature range is divided into three zones (LOW/MIDDLE/HIGH) and each ZONE has its individual PID Algorithm to provides precise and superior temperature control characteristic of whole temperature range.
3 Point calibrations – Complete temperature range is divided into three zones (LOW/MIDDLE/HIGH) and each ZONE has its individual PID Algorithm to provides precise and superior temperature control characteristic of whole temperature range.
1 Point off set calibration – Provides simple and easy calibration tool to calibrate chamber at ONE SPECIFIC TEMPERTURE POINT of frequent use.
